Max Outboard

Specifications :

• Type : Outboard Motor
• Year : Current
• Model : F200 HP In-Line 4 Cylinder Four Stroke
• Model Number : F200XB
• Series : Four Stroke High Power
• HP : 200
• Engine Type : IN-LINE 4 CYLINDER
• Displacement : 204.6 ci (3352 cc)
• Borex Stroke : 94 x 80.5 mm (3.70 x 3.17in)
• Prop Shaft Horsepower : 200 @ 5500 RPM
• Compression Ratio : 9.9
• RPM Range : 5000-6000
• Fuel Induction System : EFI Double Overhead Cam
• Fuel Type : Unleaded gasoline (minimum pump octane 87)
• Exhaust : Thru prop
• Ignition System : TCI Micro Computer
• CARB Rating : 3-Star
• Alternator Outputat WOT : 45A
• Starting System : Electric
• Lubrication : Wet Sump
• Oil Capacity : 5.9 quarts
• Recommended Engine Oil : Yamalube 4M
• Gear Ratio : 2
• Control Type : Remote
• Trolling Throttle Adjustment : +/- 50 RPM increments (600 - 1000 RPM range) via Command Link System
• Cooling : Water, Thermostatic Control
• Weight : 489 lbs (222 kg)
• Gear Shift : F-N-R
• Command Link System : Optional Equipment
• Enhanced Ultimate Corrosion Protection System UCP : Standard Feature
• Power Trim and Tilt : Yes
• Shaft Length : 25 inch
• Gearcase Rotation : Right Hand (Standard)
• Propeller : Optional Equipment
• Tiller Handle Kit : No
• Freshwater Flush : Yes
